Name: Gigabyte Netzteil UD1600GM PG5 1600Watt
Brand: Gigabyte
Price: 412.88 EUR
Availability: InStock

GIGABYTE UD1600PM PG5 AI TOP Power Supply - PCIe 5.0, 80 PLUS Platinum, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, EU Plug

412,88€

Χωρίς ΦΠΑ: 332,96€

Ποσότητα

ΤΗΛ.ΕΞΥΠΗΡΕΤΗΣΗΣ 210-3003451

100 % Ασφάλεια αγορών

Θα παραλάβεις σίγουρα την παραγγελία σου. Διαφορετικά, σου επιστρέφουμε τα χρήματά σου.

ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
80 PLUS certification	80 PLUS Platinum
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
ATX power connector (20+4 pin)	Yes
ATX version	3.1
Bearing technology	DBB
Cabling type	Fully-Modular
Combined power (+12V)	1600 W
Combined power (+3.3V)	150 W
Combined power (+5V)	150 W
Combined power (+5Vsb)	17.5 W
Combined power (-12V)	9.6 W
Cooling type	Active
CPU power connector (4+4 pin)	Yes
Depth	190 mm
Efficiency	92%
EPS power connector (4+4 pin)	Yes
Fan diameter	12 cm
Fan location	Top
Guarantee	G024M
Height	86 mm
Hold time	16 ms
Input current	15 - 7.5 A
Max output current (+12V)	133.3 A
Max output current (+3.3V)	30 A
Max output current (+5V)	30 A
Max output current (+5Vsb)	3.5 A
Max output current (-12V)	0.8 A
Mean time between failures (MTBF)	100000 h
Motherboard power cable length	61 cm
Motherboard power connector	20+4 pin ATX
Number of fans	1 fan(s)
Number of SATA power connectors	16
On/off switch	Yes
Package depth	219 mm
Package height	145 mm
Package type	Box
Package weight	5.58 kg
Package width	410 mm
PCI Express connector	Yes
PCI Express power connectors (6+2 pin)	8
Peripheral (Molex) power connectors (4-pin)	6
Power factor	0.9
Power Factor Correction (PFC) type	Active
Power Good signal delay range	100 - 150 ms
Power protection features	Over power Overheating Short circuit Over voltage Under voltage Over current
Power supply unit (PSU) form factor	ATX
Product colour	Black
Purpose	PC
SATA power cable length	650 mm 150
Total power	1600 W
Warranty period	10 year(s)
Weight	5.3 kg
Width	150 mm

GIGABYTE UD1600PM PG5 AI TOP Power Supply - PCIe 5.0, 80 PLUS Platinum, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, EU Plug
