LevelOne 8-Port Fast Ethernet PoE Industrial Switch, 4 PoE Outputs, 802.3at/af PoE, 126W, -40 C to 75 C
- Διαθεσιμότητα: Διαθέσιμο από 10 έως 30 ημέρες
- Κατασκευαστής: No name
- Κωδικός: WLONONWCRRZFT
- Βάρος(kg): 1.45kg
- Διαστάσεις Συσκευασίας: 46.50cm x 44.50cm x 15.00cm
- EAN: 4015867196663
311,53€
Χωρίς ΦΠΑ: 251,24€
ΤΗΛ.ΕΞΥΠΗΡΕΤΗΣΗΣ 210-3003451
100 % Ασφάλεια αγορών
Θα παραλάβεις σίγουρα την παραγγελία σου. Διαφορετικά, σου επιστρέφουμε τα χρήματά σου.
| ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ | |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 12 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Copper ethernet cabling technology | 10BASE-T 100BASE-TX |
| Country of origin | Taiwan |
| Depth | 36.2 mm |
| DIN rail included | Yes |
| DIN rail mounting | Yes |
| Flow control support | Yes |
| Full duplex | Yes |
| Guarantee | G024M |
| Harmonized System (HS) code | 85176990 |
| Height | 142 mm |
| LED indicators | Status Power Link |
| MAC address table | 1000 entries |
| Manual | Yes |
| Master (outer) case gross weight | 12.6 kg |
| Master (outer) case height | 570 mm |
| Master (outer) case length | 240 mm |
| Master (outer) case width | 350 mm |
| Mean time between failures (MTBF) | 510304 h |
| Networking standards | IEEE 802.3x IEEE 802.3at IEEE 802.3 IEEE 802.3u IEEE 802.3af |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 75 C |
| Package depth | 65 mm |
| Package height | 215 mm |
| Package type | Box |
| Package weight | 730 g |
| Package width | 165 mm |
| Packet buffer memory | 1 MB |
| Plug and Play | Yes |
| Power consumption (typical) | 5.76 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) voltage range | 44 - 56 V |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Product colour | Black |
| Products per master (outer) case | 16 pc(s) |
| Redundant power supply (RPS) support | Yes |
| Safety | IEC EN60950-1 |
| Store-and-forward | Yes |
| Switching capacity | 1.6 Gbit/s |
| Terminal block included | Yes |
| Terminal block port | Yes |
| Total Power over Ethernet (PoE) budget | 126 W |
| Wall mountable | Yes |
| Wall mounting kit | Yes |
| Weight | 525 g |
| Width | 105 mm |
