LevelOne 28-Port L3 Lite Managed Gigabit PoE Switch, 802.3af/at PoE, 24 PoE Outputs, 400W Power Budget, 4 x 10G SFP+, Dual AC Redundant Power Supply
- Διαθεσιμότητα: Διαθέσιμο από 10 έως 30 ημέρες
- Κατασκευαστής: No name
- Κωδικός: WLONONWCRSPB2
- Βάρος(kg): 2.98kg
- Διαστάσεις Συσκευασίας: 42.00cm x 12.00cm x 28.00cm
- EAN: 4015867241394
1.235,88€
Χωρίς ΦΠΑ: 996,68€
ΤΗΛ.ΕΞΥΠΗΡΕΤΗΣΗΣ 210-3003451
100 % Ασφάλεια αγορών
| ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ | |
| 10G support | Yes |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Access Control List (ACL) | Yes |
| ARP inspection | Yes |
| Authentication | MAC-based authentication |
| Authentication method | Login |
| Authentication type | RADIUS |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Cables included | Power |
| Compliance certificates | Federal Communications Commission (FCC) RoHS CE |
| Configuring Location Settings (CLI) | Yes |
| Copper ethernet cabling technology | 1000BASE-T 10BASE-T 100BASE-TX 1000BASE-X |
| Customs product code (TARIC) | 8517620000 |
| Depth | 350 mm |
| DHCP features | DHCP snooping DHCP client |
| Doesn't contain | Cadmium Lead Mercury |
| Ethernet Ring Protection Switching (ERPS) | Yes |
| Fanless | No |
| Fiber uplink ports quantity | 4 |
| Flash memory | 512 MB |
| Flow control support | Yes |
| Form factor | 1U |
| Forwarding rate | 190.4 Mpps |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Guarantee | G024M |
| Harmonized System (HS) code | 851762 |
| Heat dissipation | 136.48 BTU/h |
| Height | 44 mm |
| IGMP snooping | Yes |
| Internal memory | 256 MB |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Jumbo frames support | Yes |
| LED indicators | Activity System Power PoE Link |
| Link aggregation | Yes |
| MAC address table | 16000 entries |
| Market segment | Business |
| Mean time between failures (MTBF) | 100000 h |
| Memory type | Flash |
| Multicast support | Yes |
| Networking standards | IEEE 802.3 IEEE 802.3ab IEEE 802.1p IEEE 802.3at IEEE 802.3af IEEE 802.3az IEEE 802.1w IEEE 802.1Q IEEE 802.3x IEEE 802.3ad IEEE 802.1s IEEE 802.1D IEEE 802.3z IEEE 802.3u |
| Noise level | 45 dB |
| Number of power supply units | 2 |
| Number of VLANs | 4000 |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 50 C |
| Packet buffer memory | 1.5 MB |
| Power connector | AC-in jack |
| Power consumption (max) | 440 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power source | AC |
| Power supply included | Yes |
| Product colour | Grey |
| QinQ implementation | QinQ |
| Quality of Service (QoS) support | Yes |
| Quick start guide | Yes |
| Rack mount kit | Yes |
| Rack mounting | Yes |
| Redundant power supply (RPS) support | Yes |
| Security algorithms | HTTPS SNMPv2 SNMP SNMPv3 SNMPv2c |
| SFP+ module slots quantity | 4 |
| Size (imperial) | 48.3 cm (19") |
| Spanning tree protocol | Yes |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -10 - 70 C |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Switching capacity | 128 Gbit/s |
| Telnet | Yes |
| Total Power over Ethernet (PoE) budget | 400 W |
| Virtual LAN features | Protocol-based VLAN MAC address-based VLAN IP subnet based VLAN |
| VLAN support | Yes |
| Web-based management | Yes |
| Weight | 4.8 kg |
| Width | 440 mm |
