BCS BCS-L-SP0401G-1SFP-M network switch Managed Fast Ethernet (10/100) Power over Ethernet (PoE)
- Διαθεσιμότητα: Διαθέσιμο από 9 έως 15 ημέρες
- Κατασκευαστής: BCS
- Κωδικός: WLONONWCRTG86
- Βάρος(kg): 3.08kg
- Διαστάσεις Συσκευασίας: 39.00cm x 13.50cm x 44.00cm
- EAN: 5904890717138
96,81€
Χωρίς ΦΠΑ: 78,07€
ΤΗΛ.ΕΞΥΠΗΡΕΤΗΣΗΣ 210-3003451
100 % Ασφάλεια αγορών
| ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ | |
| Auto-negotiation | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Broadcast storm control | Yes |
| Cable types supported | Cat6 Cat5e |
| Cloud-managed | Yes |
| Connectivity technology | Wired |
| DC input voltage | 48 - 57 V |
| Depth | 110.4 mm |
| DHCP features | DHCP client |
| DIN rail mounting | Yes |
| Electromagnetic compatibility | Air discharge: 8 kV Contact discharge: 6 kV Common mode: 4 kV Differential mode: 2 kV |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Fast Ethernet (copper) ports quantity | 4 |
| Fiber optic connector | SFP |
| Fiber ports quantity | 1 |
| Flow control support | Yes |
| Forwarding rate | 3.57 Mpps |
| Full duplex | Yes |
| Gigabit Ethernet (copper) ports quantity | 1 |
| Guarantee | G024M |
| Half duplex | Yes |
| Height | 30 mm |
| Input voltage | 48 - 57 V |
| Loop protection | Yes |
| MAC address filtering | Yes |
| MAC address table | 8000 entries |
| Market segment | Industrial |
| Mean time between failures (MTBF) | 1852444 h |
| Multicast features | Multicast traffic suppression |
| Multicast support | Yes |
| Networking standards | IEEE 802.3u IEEE 802.3z IEEE 802.3x IEEE 802.3 IEEE 802.3ab IEEE 802.3at IEEE 802.3af IEEE 802.3bt |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -40 - 85 C |
| Port mirroring | Yes |
| Power consumption (max) | 60 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 60 W |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) PoE+ |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 1 |
| Power source | DC |
| Power supply included | Yes |
| Rack mounting | No |
| SFP module slots quantity | 1 |
| Supported network protocols | IEEE802.3 / 802.3u / 802.3x / 802.3ab / 802.3z / 802.3af / 802.3at |
| Switch type | Managed |
| Switching capacity | 4.8 Gbit/s |
| Switching optical modules type | Gigabit Ethernet |
| Switching protocols | IEEE 802.3x Flow Control, LLDP |
| System event log | Yes |
| Throughput | 4.8 Gbit/s 3.57 Mpps |
| Total Power over Ethernet (PoE) budget | 60 W |
| Virtual LAN features | Port-based VLAN |
| VLAN support | Yes |
| Web-based management | Yes |
| Weight | 320 g |
| Width | 154.3 mm |
